Cement Conditioning Tower Thermal Profile
About This Video From the Conditioning Tower Application Model.
Read More
Simulation of Cylinder Head Water Jacket Core Filling
Arena-flow is used to simulate the filling of an automotive cylinder head water jacket core through an integrated core print.
Root Cause of FCCU Flue Gas Line Afterburn
This video shows the hydrodynamics, thermal profile and effect of combustion reactions in an FCC regenerator.
Uphill Sand Flow
Arena-flow, by CPFD, models the air-driven sand flow critical to the creation of consistent, high-quality sand cores and molds for many processes including cold-box, shell, inorganics, greensand, hot-box, and warm-box. This video illustrates how air flow drags sand into the cavity.
Biomass Gasifier for Novel Waste-to-Fuels Technology
This video shows how Barracuda Virtual Reactor was leveraged by ThermChem Recovery International, USA (TRI) for the research, development, and scale-up of their novel waste-to-fuels technology.
Cold Box Curing, Gas and Air Progress Inside Tool
This video shows how a mixture of gas and air progresses inside a core box, as the sand has contact with gas, air, cured sand, in this instance cured sand is shown as transparent dark grey.
Bubble Coalescence in Virtual Reactor 23.1
This simulation video demonstrates Barracuda Virtual Reactor’s capability to model bubble coalescence and breakup in multiphase system, a feature introduced in version 23.1.
Arena-flow Inorganic Curing Demonstration
This video demonstrates Arena-flow’s inorganic curing capabilities for dehydrative systems.
Full Magazine Simulation, Pressure and Sand Ratio
This video demonstrates the air-sand motion computed by Arena-flow for a magazine used to fill multiple sand cores. As the magazine pressurizes, the air drags sand into the core.
Multiphase (VLS) simulation of an FCC Riser with Evaporation
This video demonstrates some of the new multiphase simulation capabilities for vapor/liquid/solid (VLS) systems available in Barracuda Virtual Reactor 22.
